Double Ended Lamp
Commercial Lighting
Applications
Features
Double Ended Lamps
| Description | Base | Part code | Initial Lumens* | Avg. Life Hours* | Color Temp. | CRI | LPW | Burn Position | Lamp Op. Cur. (A) | Carton Qty | Control Gear |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MH-DE 70 W/UVS/3K | Rx7s | 16786 | 5200 | 10000 | 3000 | 70 | 69 | Hor ± 45* | 0.90 | 25 | MH / HPSV |
| MH-DE 70 W/UVS/4K | Rx7s | 60248 | 5500 | 10000 | 4200 | 70 | 73 | Hor ± 45* | 0.90 | 25 | MH / HPSV |
| MH-DE 70W/UVS/FS/6K | Rx7s | 79470 | 4800 | 10000 | 6500 | 90 | 64 | Hor ± 45* | 0.90 | 25 | MH / HPSV |
| MH-DE 150 W/UVS/3K | Rx7s | 11295 | 11250 | 10000 | 3000 | 70 | 75 | Hor ± 45* | 1.80 | 25 | MH / HPSV |
| MH-DE 150 W/UVS/4K | Rx7s | 74756 | 11250 | 10000 | 4200 | 70 | 75 | Hor ± 45* | 1.80 | 25 | MH / HPSV |
| MH-DE 150W/UVS/FS/6K | Rx7s | 29963 | 11250 | 10000 | 6500 | 90 | 75 | Hor ± 45* | 1.80 | 25 | MH / HPSV |
| MH-DE 250 W/UVS/3K | Fc2 | 84727 | 20000 | 10000 | 3000 | 70 | 80 | Hor ± 45* | 3.00 | 25 | MH / HPSV |
| MH-DE 250 W/UVS/4K | Fc2 | 72748 | 20000 | 10000 | 4200 | 70 | 80 | Hor ± 45* | 3.00 | 25 | MH / HPSV |
* When operated in horizontal burn position
