LED Lighting

LED Bulb

Vision Bulb

 Vision Bulb
 Vision Bulb
 Vision Bulb

Specifications & Features

  • Integrated injection thermo-bio plastic housing with extruded aluminum heat sink
  • 80% energy saving Vis a Vis conventional GLS
  • Standard B22d / E27 base for direct GLS/CFL replacement
  • More than 85% driver efficiency
  • Wide operating voltage 100 - 275V
  • Color Rendering Index (CRI) > 80
  • Working ambient temperature -20°C to + 45°C
  • Anticipated Life - 10,000Hrs used in an open fitting
  • High intensity of illumination with 240°view angle
  • Flicker free instant start electronic operation
  • Electric wave & radio interference free
  • Without mercury, UV & IR radiation
  • IP 20 Ingress Protection
  • Applications

  • Hotels
  • Restaurant
  • Offices
  • Institution
  • General Lighting
  • Residential Lighting
  • Technical & Ordering Information

    Product ID / Ordering Code Product Description Wattage(W) Nominal Voltage(V) Mains Current(A) CCT (K) Lumen (lm)
    VL/BLB-LC-LED00565 Vision LED Bulb 05/CW B22d 5 230 0.024 6500 500
    VL/BLB-LC-LED00530 Vision LED Bulb 05/WW B22d 5 230 0.024 3000 500
    VL/BLB-LC-LED00765 Vision LED Bulb 07/CW B22d 7 230 0.033 6500 700
    VL/BLB-LC-LED00730 Vision LED Bulb 07/WW B22d 7 230 0.033 3000 700
    VL/BLB-LC-LED00965 Vision LED Bulb 09/CW B22d 9 230 0.042 6500 900
    VL/BLB-LC-LED00930 Vision LED Bulb 09/WW B22d 9 230 0.042 3000 900
    VL/BLB-LC-LED01265 Vision LED Bulb 12/CW B22d 12 230 0.055 6500 1200
    VL/BLB-LC-LED01230 Vision LED Bulb 12/WW B22d 12 230 0.055 3000 1200
    Lamp Enclosed Rated

    *xx also available in 3000K CCTs on request.
