Specifications & Features
Applications
Installation & Maintenance
Technical & Ordering Information
| Product ID / Ordering Code | Product Description | Wattage(W) | Nominal Voltage(V) | Mains Current(A) | CCT (K) | Lumen (lm) |
|---|---|---|---|---|---|---|
| VL/HBL-002-LED03050 | Venus LED High Bay COB 30/CW | 30 | 230 | 0.135 | 5000 | 2700 |
| VL/HBL-002-LED04065 | Venus LED High Bay COB 40/CW | 40 | 230 | 0.180 | 6500 | 3600 |
| VL/HBL-002-LED05050 | Venus LED High Bay COB 50/CW | 50 | 230 | 0.225 | 5000 | 4500 |
| VL/HBL-002-LED06065 | Venus LED High Bay COB 60/CW | 60 | 230 | 0.274 | 6500 | 5400 |
| VL/HBL-002-LED08065 | Venus LED High Bay COB 80/CW | 80 | 230 | 0.365 | 6500 | 7200 |
| VL/HBL-002-LED10050 | Venus LED High Bay COB 100/CW | 100 | 230 | 0.455 | 5000 | 9000 |
| VL/HBL-002-LED12050 | Venus LED High Bay COB 120/CW | 120 | 230 | 0.540 | 5000 | 10800 |
| VL/HBL-002-LED15050 | Venus LED High Bay COB 150/CW | 150 | 230 | 0.680 | 5000 | 13500 |
| VL/HBL-410-LED20057** | Venus HVAC LED High Bay 200/CW | 200 | 230 | 0.915 | 5700 | 18000 |
*xx also available in 3000K, 4000K, 5000K CCTs on request.
** 410 series high bay are with HVAC Technology & having operating voltage range 180 - 270Vac
